Summary:

The HMI user interface in the industrial design field of human-computer interaction, is the space where interactions between humans and machines occur. The goal of this interaction is to allow effective operation and control of the machine from the human end, whilst the machine simultaneously feeds back information that aids the operators’ decision-making process. Generally, the goal of user interface design is to produce a user interface which makes it easy, efficient, and enjoyable (user-friendly) to operate a machine in the way which produces the desired result. This generally means that the operator needs to provide minimal input to achieve the desired output, and also that the machine minimizes undesired outputs to the human.

Solution:

The E1071 HMI operator panels offer comprehensive HMI functionality and feature a robust IP66 aluminum construction and multiple communication ports. Choose from standard models with touchscreen display or with keypad control. The E1071 series complies with global industry standards and is suitable for most industrial environments.

Features of HMI:

640 x 480 pixels
TFT display
6.5″ TFT-LCD touch screen
Project storage 12 MB
Operating temperature 0 to +50 °C
Ethernet and serial
Touch display

X2 pro includes a wide range of high-performance industrial panels designed for demanding applications. All with the high performance of powerful ARM Cortex-A9 processors, the latest screen technology and a wide range of connectivity options to cover all your automation needs.X2 pro also include a number of web HMIs perfect for enterprises and users who wants to utilize HTML5 web technologies in industrial environments. The X2 web HMIs enable visualization of the same content across different target platforms such as mobile, tablet, pc, etc. without any conversion or re-engineering.

Features of HMI:

• 800 × 480 pixel (16:9)
• TFT-LCD touch screen
• 1.5 GB application memory
• Ethernet 1×100 Mbit
• -10°C to +60°C operating temperature
• CE, FCC, KCC, UL approvals
• DNV GL, KR, LR, ABS, CCS, BV, NK marine approvals

When compared to E1071 HMI, the X2 Pro is very advanced and High performed one and it also have many connectivity options than the E1071 HMI. So in order to get more ease and high reliability we used the X2 Pro HMI.
